Vacuum Circuit Breaker Panel
Pioneers in the industry, we offer vacuum circuit breaker panel outdoor type and outdoor vcb panel from India.
Vacuum Circuit Breaker Panel Outdoor Type
| Minimum Order Quantity | 1 Unit |
|---|---|
| Color | 12/28/75KVP |
| Brand | ABB CROMPTON SCHNEIDER SIEMENS L&T |
| Material | 11KV VCB INDOOR /OUTDOOR |
| Power | 11 kV,22 kV,33kV |
| Application | Transformer Protection or HT DG Sets Protection |
| Phase | 3 |
| Approx. Price | ₹6.8 Lakh / Unit |
We are recognized as successful manufacturers and traders of HT Panels. These panels are made available to our customers as per the set industry norms and at extremely feasible rates as well. When the contacts of the breaker are opened in a vacuum, an arc is produced between the contacts by the ionization of metal vapors of contacts. However, the arc is quickly extinguished because the metallic vapors, electrons, and ions produced by arc rapidly condense on the surfaces of the circuit breaker contacts, resulting in the quick recovery of dielectric strength.
Features :
- Smooth and continuous dimming
- Powerful backup
- Control mechanism
Outdoor VCB Panel
| Minimum Order Quantity | 1 Unit |
|---|---|
| Rated Voltage | 3.3KV 6.6KV 11KV 33KV |
| Rated Current | 400A 4500A |
| No. of Poles | 3 |
| Impulse Withstand Voltage | 3.3KV 6.6KV 11KV 33KV |
| Breaking Capacity | 20KA 25KA 40KA |
| Rated Insulation Level | 12/28/75KVP 36/70/170KV |
| Brand | ABB |
| Applicable Standard | AS PER IS |
| Approx. Price | ₹3.9 Lakh Lakh / Unit |
In order to retain remarkable position in this industry, we are providing a wide array of 11Kv HT Vacuum Circuit Breaker
